Matrix Audio MD-1 Streaming Integrated Amplifier
The MD-1 is Matrix Audio’s most affordable streaming integrated amplifier, combining a network streamer, DAC, phono stage and 150W-per-channel amplifier in one chassis. HDMI ARC, two optical and two coaxial inputs, and HD Bluetooth cover analogue and digital sources. Supports most major streaming services.
Usually dispatched in 2-3 days. Delivery & returns
£3,499.00
including delivery and VAT
Have a question? Call us on 0161 399 0993 or contact us. We also offer part exchange and price matching.
About the Matrix Audio MD-1
The MD-1 is Matrix Audio’s most affordable streaming integrated amplifier – a network streamer, DAC, preamp and 150W-per-channel power amplifier built into one chassis, so a pair of passive speakers is all that’s needed to build a complete system around it.
It shares its digital and streaming platform with the rest of Matrix Audio’s range, but adds a proper amplifier stage, a phono input and a wide set of TV and computer connections, aimed at anyone who wants one box to do the whole job. For more headroom or a larger room, the MD-1P steps up to 300W per channel with dual switchable speaker outputs.
Power and amplification
Output is rated at 150W per channel into 8 ohms, with output impedance below 5mΩ and +30dB of gain, enough to drive most bookshelf and floorstanding speakers with authority. PWM-based amplification keeps efficiency high and heat low compared with a conventional Class A/B design, and a single pair of Matrix Audio’s own gold-plated, solid copper speaker terminals keeps the connection to the speaker cable itself low-resistance.
Clocking, conversion and volume control
The digital side runs on two custom femtosecond clocks, one referenced to 44.1kHz and one to 48kHz, paired with an FPGA handling clock division and jitter reduction. The digitally-controlled analogue volume control provides 256 steps from -80dB to +12dB in 0.5dB increments. The voltage curve is tuned to keep left and right channels in phase even at low volumes, and it has a 12-step channel balance for fine positioning.
Sources and connectivity
A built-in MM phono stage with a RIAA-tuned, low-noise design means a turntable connects straight in, alongside XLR and RCA line inputs, with a bypass mode that turns the MD-1 into a pure power amp for an AV system.
On the digital side there’s HDMI ARC for a TV, USB for a computer, two optical and two coaxial inputs for other digital sources, and Bluetooth 5.0 with aptX HD and LDAC for convenient ad hoc streaming.
Preamp and subwoofer outputs share the same volume control as the speaker terminals, with a low-frequency output below 150Hz and a trigger connection to bring a subwoofer on automatically.
Storage and streaming
An NVMe SSD bay gives the MD-1 its own local library, shared over the network via SMB or as a NAS for other streamers in the house. CDs rip automatically from an external USB drive through the MA Remote App, turning a physical collection into digital files without a computer. Roon Ready, with TIDAL, Qobuz, Audirvana and the usual streaming services all supported.
Features
Power & amplification
150W per channel
Into 8 ohms, with +30dB of gain and output impedance below 5mΩ.
PWM-based amplification
High efficiency with lower heat than a conventional Class A/B design.
Gold-plated copper speaker terminals
A single pair, custom-designed for low resistance and a secure grip on speaker cable.
Preamp and subwoofer output
Synchronised volume control, with a dedicated low-frequency output below 150Hz and trigger-based subwoofer power-on.
Conversion & clocking
Dual femtosecond clocks and FPGA
Separate references for the 44.1kHz and 48kHz families, with FPGA-based clock division and jitter reduction.
Digitally-controlled analogue volume
-80dB to +12dB in 0.5dB steps, with 12-step channel balance and phase-matched left/right tracking.
Inputs & connectivity
MM phono input
RIAA-equalised, low-noise phono stage for a turntable connected directly.
XLR and RCA line inputs
With a bypass mode that turns the MD-1 into a pure power amp for AV integration.
HDMI ARC, USB and digital inputs
HDMI ARC for a TV, USB for a computer, and two optical and two coaxial inputs for other digital sources.
HD Bluetooth 5.0
aptX, aptX HD, AAC, SBC and LDAC support, for streaming without a wired connection.
Sources & streaming
MA Player streamer OS
Matrix Audio’s own Linux-based platform runs everything from local files to internet radio.
Roon Ready and streaming services
Native support for TIDAL Connect, Qobuz Connect, Spotify Connect, AirPlay 2, DLNA/UPnP, vTuner, Radio Paradise and Audirvana.
Internal NVMe SSD bay
Shareable over SMB, or as a NAS for other streamers on the network.
CD ripping via USB
Rip CDs from an external USB drive straight to internal storage via the MA Remote App.
MA Remote App
Full control from iOS, iPadOS and Android.
Specifications
| Brand | Matrix Audio |
|---|---|
| Colour | Silver |
| Digital Inputs | 2 x coaxial, 2 x optical, HDMI ARC, USB |
| Coaxial/Optical Input Resolution | PCM up to 24-bit/192kHz, DSD64 via DoP |
| HDMI ARC Input Resolution | PCM up to 24-bit/192kHz |
| USB Input Resolution | PCM up to 32-bit/768kHz, DSD up to DSD512 native or DSD256 via DoP |
| Bluetooth | Bluetooth 5.0, aptX/aptX HD/AAC/SBC/LDAC, PCM up to 16-bit/96kHz, 10–15m range |
| Line Inputs | XLR (47kΩ, max 8Vrms), RCA (47kΩ, max 4Vrms), with bypass mode |
| Phono Input | MM, 47kΩ/100pF, +40dB gain, RIAA equalised |
| Pre Output (RCA) | <20Ω impedance, 0–2.2Vrms adjustable, SNR 120dB A-weighted, THD+N <0.0005% @1kHz, crosstalk >-115dB |
| Subwoofer Output (RCA) | <20Ω impedance, 150Hz cutoff, 0–2.2Vrms adjustable |
| Speaker Output | 2 x 150W @8Ω, output impedance <5mΩ, gain +30dB, speaker impedance 2–16Ω |
| Amplifier Performance | 20Hz–20kHz ±0.1dB, -3dB @45kHz; SNR 122dB A-weighted; crosstalk -120dB |
| Network | Gigabit Ethernet, 2.4GHz/5GHz Wi-Fi |
| USB (Storage) | USB 3.0, 5V/1A, supports FAT, FAT32, exFAT and NTFS filesystems |
| Internal Storage | M.2 2280/2242/2230 NVMe SSD, PCIe 3.0/4.0/5.0, max 3.3V/3A |
| Local Playback Formats | MP3, WMA, WAV, AIF/AIFC/AIFF, AAC, FLAC, OGG, APE, ALAC, M4A, DSF, DFF, CUE and ISO |
| Local Playback Resolution | PCM up to 32-bit/768kHz, DSD up to DSD512 |
| Streaming Support | Roon Ready, Audirvana, TIDAL Connect, Qobuz Connect, Spotify Connect, AirPlay 2, DLNA/UPnP, vTuner and Radio Paradise |
| Control App | MA Remote App (iOS, iPadOS and Android) |
| Remote | IR remote |
| Trigger In | DC 6–12V, <10mA |
| Trigger Out | DC 12V, 50mA max |
| Power Voltage | 100–240V 50/60Hz, auto-sensing |
| Standby Consumption | <5W |
| Idle Consumption | <35W |
| Max Consumption | <700W |
| Dimensions (W x D x H) | 430 x 331 x 96 mm |
| Weight | 7.0 kg |
In the box
- MD-1 amplifier
- Power cable
- IR remote
- Quick start guide
- Warranty card
