Exposure XM5 Integrated Amplifier

Exposure XM5 Integrated Amplifier

The Exposure XM5 integrated amplifier is part of Exposure’s recently introduced XM series of compact half width components. It combines a 60 watts per channel integrated amplifier, a DAC with asynchronous USB and DSD support, and a moving magnet phono stage.

Gallery

|

Learn More

The Exposure XM5 integrated amplifier is part of Exposure’s recently introduced XM series of compact half width components. It combines a 60 watts per channel integrated amplifier, a DAC with asynchronous USB and DSD support, and a moving magnet phono stage.

Features

  • Large 200 W custom made toroidal power transformer
  • High quality all aluminium casework and extruded front panel
  • High quality resistors and capacitors used in the signal path
  • Cascode circuitry utilised for improved power supply immunity
  • Toshiba bipolar output transistors for dynamics and performance
  • 60 W per channel into 8 ohms
  • Moving magnet phono input, fixed level AV input and one line level input
  • Two coax (BNC) and two optical inputs and one class 2 USB input with DSD support
  • Separate pre-amp output
  • Remote control
Brand

Colour

Black, Titanium
Power Output

2 x 60 W (8 Ω)
Distortion

<0.01% for 60 W @ 1 kHz
Frequency Response

20 Hz – 20 kHz ±0.5 dB
Channel Separation

>40 dB @ 20 kHz, >60 dB @ 1 kHz
Audio Inputs

1 x USB type B, 2 x coaxial digital RCA, 2 x optical digital Toslink, 3 x RCA (including one AV bypass)
Audio Outputs

RCA preamp output, Speaker terminals compatible with 4 mm banana plugs
Power Consumption

200 W (both channels driven 8 Ω load)
Dimensions (WxDxH)

218 x 363 x 89 mm
Weight

5 kg
Warranty

3 years
